ABB TAC-W7-G5-R-0 AC Charger Wall box 1 Ph 230VAC 7 kW 5m L Cable RFID App Free VenDINg

Product Code: TAC-W7-G5-R-0

  • DC residual current detection
  • Contactor welding detection
  • Networkable via LAN
  • Networkable via Wi-Fi
  • Long-term evolution (LTE)
In Stock Low Stock Out Of Stock Please See Attributes

Specifications

Product Type AC Charger Wall box
Brand ABB
Authentication Method RFID, App, Free Vending
Cable Length 5 m
Communication/Memory Interface Wi-Fi, Ethernet, Bluetooth, Modbus
Cross Section 6 sq-mm
Energy Meter Type AC
Housing Material Plastic
Mounting Type Wall
Number of Phases 1
Overload Protection 40 A
Rated Current 32 A
Rated Frequency 50/60 Hz
Rated Power 7 kW
Rated Voltage 230 VAC
Temperature Rating -30 to 50 deg C
Width 195 mm
Degree of Protection IP54

Description

The Terra AC charger is designed specifically for electric vehicles. It features RFID technology and comes with a 5m type 2 cable. With a voltage rating of 230 VAC single phase, it has a rated power of 7.4kW and a maximum current of 32 A.The charger is housed in an enclosure with an IP54 protection degree, ensuring durability and resistance to dust and water ingress.Connectivity options include Wifi, Bluetooth, and Ethernet, allowing for easy integration into existing networks.The charger also includes a built-in energy meter and can be integrated with advanced energy systems for dynamic load management.Safety features are comprehensive, including protection against overcurrent, overvoltage, undervoltage, ground fault, surge protection, and protective earth continuity monitoring.Additionally, the charger is enabled for remote software updates, ensuring that it stays up-to-date with the latest features and improvements.

Documents

  • IPD Product Catalogue

    IPD Product Catalogue V17

All Attributes Data

number TAC-W7-G5-R-0
id 6811dda5ed49b666d530c739
attributes_value
attributes_name
media_fileName
media_labels
media_downloadUri
media_name
description The Terra AC charger is designed specifically for electric vehicles. It features RFID technology and comes with a 5m type 2 cable. With a voltage rating of 230 VAC single phase, it has a rated power of 7.4kW and a maximum current of 32 A.The charger is housed in an enclosure with an IP54 protection degree, ensuring durability and resistance to dust and water ingress.Connectivity options include Wifi, Bluetooth, and Ethernet, allowing for easy integration into existing networks.The charger also includes a built-in energy meter and can be integrated with advanced energy systems for dynamic load management.Safety features are comprehensive, including protection against overcurrent, overvoltage, undervoltage, ground fault, surge protection, and protective earth continuity monitoring.Additionally, the charger is enabled for remote software updates, ensuring that it stays up-to-date with the latest features and improvements.
