Schmersal 153031629 Position Switch 230VAC, 24VDC

Product Code: 153031629

  • Supports 230 VAC & 24 VDC, rated at 3 A
  • Durable with 1 million cycle lifespan
  • Robust grey cast iron housing, painted finish
  • IP66 protection for harsh environments
  • Operates from -40 to 70°C
In Stock Low Stock Out Of Stock Please See Attributes
1

Specifications

General

Product Type
Position Switch (Heavy - Duty, Platform Concept, Slow Action)
Brand
Schmersal
Series
BS655

Electrical

No. of N/C Contacts
2
No. of N/O Contacts
2
Rated Current (In)
3A, 3A
Rated Voltage (Ur)
230V AC, 24V DC
Terminal Type
Screw terminals

Mechanical

Actuator Type
Actuator/lever ordered separately (base switch, no lever fitted); slow-action switching
Housing Material
Grey cast iron, painted

Dimensions & Physical Data

Weight
6.11kg

Environmental

Operating Temperature
-40°C to 70°C
IP Rating
IP66, IP67

Documents

IPD Product Catalogue V17
