Schmersal 153031619 Pull-Wire Emergency Stop Switch

Product Code: 153031619

  • Rated current of 3A for reliable performance
  • Durable roller lever actuator
  • Long mechanical life: 100,000 cycles
  • Robust thermosetting resin housing
  • IP66 protection against dust and water
In Stock Low Stock Out Of Stock Please See Attributes
1

Specifications

General

Product Type
Pull - Wire Emergency Stop Switch
Brand
Schmersal
Series
RS656

Electrical

No. of N/C Contacts
2
No. of N/O Contacts
2
Rated Current (In)
3A at 230V AC, 3A at 24V DC
Rated Voltage (Ur)
230V AC, 24V DC
Terminal Type
Cage clamp

Mechanical

Cable Entry
2 x M25 x 1.5
Housing Material
Thermosetting resin

Dimensions & Physical Data

Depth
163mm
Height
234mm
Weight
2.83kg
Width
108mm

Environmental

IP Rating
IP66, IP67
Ambient Temperature
-40°C to 70°C

Documents

IPD Product Catalogue V17
