Schmersal 153031614 Pull-Wire Emergency Stop Switch

Product Code: 153031614

  • Operates at 230 VAC, 3 A
  • Durable roller lever actuator
  • Robust grey cast iron housing
  • High protection rating of IP66
  • Compliant with EN IEC 60947-5-1 standards
In Stock Low Stock Out Of Stock Please See Attributes
1

Specifications

General

Product Type
Pull - Wire Emergency Stop Switch
Brand
Schmersal
Series
RS655

Electrical

No. of N/C Contacts
2
No. of N/O Contacts
2
Rated Current (In)
3A at 230V AC, 3A at 24V DC
Rated Voltage (Ur)
230V AC, 24V DC
Terminal Type
Cage clamp

Mechanical

Cable Entry
2 x M25 x 1.5
Housing Colour
Grey
Housing Material
Grey cast iron, painted

Dimensions & Physical Data

Depth
163mm
Height
234mm
Weight
6.14kg
Width
105mm

Environmental

IP Rating
IP66, IP67
Ambient Temperature
-25°C to 60°C

Documents

IPD Product Catalogue V17
