Schmersal 151181529 Foot Switch 1NO-1NC 230VAC 24VDC 4A 1A

Product Code: 151181529

  • Aluminium housing, robust and durable
  • IP65 protection against dust and water
  • Rated for 230 VAC and 24 VDC
  • Contact config: 1NO+1NC, slow action
  • Complies with ENISO 13849-1 standards
In Stock Low Stock Out Of Stock Please See Attributes
1

Specifications

General

Product Type
Foot Switch
Brand
Schmersal
Series
232

Electrical

No. of N/C Contacts
1
No. of N/O Contacts
1
Rated Current (In)
4A AC, 1A DC
Rated Voltage (Ur)
230V AC, 24V DC

Mechanical

Actuator Type
Pedal
Housing Colour
RAL 9006 (White aluminum)
Housing Material
Aluminium

Dimensions & Physical Data

Depth
274mm
Height
189mm
Weight
1.63kg
Width
170mm

Environmental

Operating Temperature
-25°C to 70°C
IP Rating
IP65

Documents

IPD Product Catalogue V17
