Schmersal 131151773 Position Switch with Safety Function 230VAC

Product Code: 131151773

  • Operates at 230 VAC, 2 A
  • IP40 protection for indoor use
  • Durable die-cast light alloy housing
  • Roller lever actuating element
  • Complies with EN IEC 60947-5-1 standards
In Stock Low Stock Out Of Stock Please See Attributes
1

Specifications

General

Product Type
Position Switch
Brand
Schmersal

Electrical

No. of N/C Contacts
1
No. of N/O Contacts
1
Rated Insulation Voltage (Ui)
500V
Thermal Test Current
6A

Mechanical

Actuator Type
Roller lever
Housing Material
Light alloy die-casting

Dimensions & Physical Data

Depth
60.5mm
Height
129.5mm
Weight
0.312kg
Width
40mm

Environmental

IP Rating
IP65,IP67
Ambient Temperature
-30°C to 80°C

Documents

IPD Product Catalogue V17
