Schmersal 103008214 E Emergency-Stop button 38.5 mm 2NO+2NC

Product Code: 103008214

  • 2NO contact configuration for versatile use
  • Durable roller lever actuator
  • Compact size: 46mm x 29mm x 65mm
  • High protection: IP20, IP40, IP65
  • Operates in -25 to 80°C range
In Stock Low Stock Out Of Stock Please See Attributes
1

Specifications

General

Product Type
Emergency Stop Button
Brand
Schmersal
Series
E

Electrical

No. of N/C Contacts
2
No. of N/O Contacts
2
Illumination
Non-illuminated
Rated Current (In)
AC-15: 8A,DC-13: 5A
Rated Voltage (Ur)
AC-15: 230V,DC-13: 24V
Terminal Type
Screw terminals

Mechanical

Pushbutton Colour
Red
Pushbutton Material
ABS
Pushbutton Type
External Jump Mechanism
Unlocking Method
Rotating draw unlatcher

Dimensions & Physical Data

Mounting Hole Diameter (mm)
22mm
Button Diameter (mm)
38.5mm

Environmental

IP Rating
IP67IP69IP69K

Documents

IPD Product Catalogue V17
