Schmersal 103007672 Multi-Function Safety Relay Module

Product Code: 103007672

  • Durable glass fibre reinforced thermoplastic housing
  • High protection with IP67 rating
  • Operates efficiently up to 80°C
  • Complies with BG-GS-ET-19, EN IEC 60947-5-1 standards
  • Compact design with 50 mm sensor length
In Stock Low Stock Out Of Stock Please See Attributes
1

Specifications

General

Product Type
Safety Relay
Brand
Schmersal
Series
SRB-E

Electrical

Switching Current
Up to 6 A
Switching Voltage
Up to 230 V AC
Supply Voltage
24V DC

Mechanical

Housing Material
Glass-fibre reinforced thermoplastic

Dimensions & Physical Data

Depth
115mm
Height
98mm
Weight
0.175kg
Width
22.5mm

Environmental

IP Rating
IP40 (housing), IP20 (terminals)
Ambient Temperature
-25°C to 60°C

Safety, Standards & Compliance

Auxiliary Relay Outputs
1 auxiliary contact
Safe Relay Outputs, Stop 0
3 NO
Safety Integrity Level
SIL 3
Monitoring Circuit
Feedback + safety device monitoring
Performance Level
PL e

Documents

IPD Product Catalogue V17
