Schmersal 103007625 EX Belt Alignment Switch Glass Fibre Reinforced Thermoplastic

Product Code: 103007625

  • Belt alignment switch for efficient monitoring
  • Operates on 10-49 VDC voltage range
  • Durable glass fibre reinforced thermoplastic housing
  • IP20 protection against solid objects
  • Complies with BG-GS-ET-19, ENIEC 60947-5-1 standards
In Stock Low Stock Out Of Stock Please See Attributes
1

Specifications

General

Product Type
Belt - Alignment Switch
Brand
Schmersal
Series
EX-441 Belt Alignment Switch

Electrical

No. of N/C Contacts
1
No. of N/O Contacts
1
Rated Insulation Voltage (Ui)
400V
Rated Current (In)
4A
Rated Voltage (Ur)
400V AC
Thermal Test Current
16A

Mechanical

Contact Material
Gold-plated silver
Housing Material
Grey cast iron, galvanised

Environmental

IP Rating
IP65,IP66,IP67
Ambient Temperature
-20°C to 60°C

Documents

IPD Product Catalogue V17
