Schmersal 101215516 Magnetic Safety Sensor

Product Code: 101215516

  • Durable glass fibre reinforced thermoplastic housing
  • IP67 protection for robust environmental resistance
  • Designed for 20 million mechanical cycles
  • Compact size: 30 mm L x 179 mm H
  • Operates at a safe 24 VDC, 0.01 A
In Stock Low Stock Out Of Stock Please See Attributes
1

Specifications

General

Product Type
Magnetic Safety Sensor
Brand
Schmersal
Series
BNS 40S

Electrical

No. of N/C Contacts
2
No. of N/O Contacts
1
Rated Current (In)
0.01A
Rated Voltage (Ur)
24V DC

Mechanical

Actuator Type
BPS 40S-1; BPS 40S-2-C; BPS 40S-2; BPS 40S-1-C
Housing Material
Stainless steel (V4A)

Dimensions & Physical Data

Depth
14mm
Height
27mm
Weight
0.25kg
Width
88mm
Cable Length
1m

Environmental

Operating Temperature
-25°C to 75°C
IP Rating
IP69

Documents

IPD Product Catalogue V17
