Schmersal 101208309 Safety Relay Module 24VDC

Product Code: 101208309

  • Operates at 24 VDC with 2.4 W power
  • Durable metal, die cast zinc housing
  • IP20 protection rating for safety
  • Mechanical life of 1 million cycles
  • Complies with EN IEC 60947-5-1 standards
In Stock Low Stock Out Of Stock Please See Attributes
1

Specifications

General

Product Type
Safety Relay Module
Brand
Schmersal
Series
SRB211ST (V2)

Electrical

Switching Current
8:00 AM
Switching Voltage
250 V AC
Supply Voltage
24 V AC, 24 V DC

Mechanical

Housing Material
Glass-fibre reinforced thermoplastic, ventilated

Dimensions & Physical Data

Depth
121 mm
Height
100 mm
Weight
280 g
Width
22.5 mm

Environmental

Operating Temperature
-25 to 70 °C
IP Rating
IP40, IP54, IP20

Safety, Standards & Compliance

Auxiliary Semiconductor Outputs
1
Safe Relay Outputs, Stop 0
3
Safe Relay Outputs, Stop 1
2
Safety Category
4 (Stop 0), 3 (Stop 1)
Safety Integrity Level
SIL 3 (Stop 0), SIL 2 (Stop 1)
Monitoring Circuit
Yes
Performance Level
PL e (Stop 0), PL d (Stop 1)
