Schmersal 101199623 Solenid Interlock Switch

Product Code: 101199623

  • Durable glass fibre reinforced thermoplastic housing
  • High protection levels: IP65, IP67
  • Operates in temperatures from -25 to 55°C
  • Complies with multiple international safety standards
  • Rated insulation voltage of 32V
In Stock Low Stock Out Of Stock Please See Attributes
1

Specifications

General

Product Type
Solenoid Interlock Switch
Brand
Schmersal
Series
MZM 100

Electrical

Switching Current
4A (AC-15), 1A (DC-13)
Rated Voltage (Ur)
24V AC/ DC (control)
Terminal Type
Connector M12, 8-pole
Operating Mode
Power-to-lock

Mechanical

Guard Locking Force
750N
Housing Material
Glass-fibre reinforced thermoplastic

Dimensions & Physical Data

Depth
40mm
Height
179mm
Weight
0.618kg (approx.)
Width
40mm

Environmental

IP Rating
IP67
Ambient Temperature
-25°C to 50°C
