Schmersal 101195484 Safety Switch with Separate Actuator 1NO+1NC

Product Code: 101195484

  • 1NO+1NC contact configuration
  • Durable for 10 million cycles
  • IP65 protection rating
  • Operates from -25 to 65°C
  • Complies with EN IEC standards
In Stock Low Stock Out Of Stock Please See Attributes
1

Specifications

General

Product Type
Safety Switch With Separate Actuator (Ex - Certified)
Brand
Schmersal
Series
EX-AZ 16

Electrical

No. of N/C Contacts
2
No. of N/O Contacts
1
Terminal Type
Screw terminals M20 x 1.5

Mechanical

Housing Material
Plastic, glass-fibre reinforced thermoplastic, self-extinguishing

Dimensions & Physical Data

Depth
30mm
Height
90mm
Weight
0.14kg
Width
52mm

Environmental

Operating Temperature
-20°C to 70°C
IP Rating
IP67

Documents

IPD Product Catalogue V17
