Schmersal 101184004 Safety Switch with Separate Actuator 230VAC, 24VDC 1NO+1NC 5m Cable

Product Code: 101184004

  • Supports 230 VAC and 24 VDC voltage
  • Handles up to 1000 A current
  • Durable with 1 million cycle life
  • IP67 protection for harsh environments
  • Operates in -30 to 80°C temperatures
In Stock Low Stock Out Of Stock Please See Attributes
1

Specifications

General

Product Type
Safety Switch With Separate Actuator
Brand
Schmersal
Series
AZ 17

Electrical

No. of N/C Contacts
1
No. of N/O Contacts
1
Terminal Type
Pre-wired cable

Mechanical

Cable Entry
Pre-wired cable
Housing Material
Plastic, glass-fibre reinforced thermoplastic, self-extinguishing

Dimensions & Physical Data

Depth
30mm
Height
65mm
Weight
0.422kg
Width
30mm

Environmental

Operating Temperature
-30°C to 80°C
IP Rating
IP67

Documents

IPD Product Catalogue V17
