Schmersal 101182706 Safety Hinge Switch NC

Product Code: 101182706

  • 100 A safety switch with roller lever actuator
  • Durable glass fibre reinforced thermoplastic housing
  • IP65 protection for harsh environments
  • Long mechanical life of 10 million cycles
  • Complies with EN 81-20/EN 81-50 standards
In Stock Low Stock Out Of Stock Please See Attributes
1

Specifications

General

Product Type
Safety Hinge Switch
Brand
Schmersal
Series
TESF

Electrical

No. of N/C Contacts
2
No. of N/O Contacts
2
Rated Current (In)
2A, 1A
Rated Voltage (Ur)
230V AC, 24V DC
Terminal Type
Screw terminals

Mechanical

Cable Entry
2 x M16 x 1.5
Housing Colour
Black
Housing Material
Metal, zinc die-cast

Dimensions & Physical Data

Depth
21.5mm
Height
115mm
Weight
0.616kg
Width
141mm

Environmental

Operating Temperature
-25°C to 65°C
IP Rating
IP65
