Schmersal 101177733 Magnetic Safety Sensor

Product Code: 101177733

  • Operates at 24 VDC, consuming only 0.24 W
  • Durable with a mechanical life of 25 million cycles
  • Sturdy glass fibre reinforced thermoplastic housing
  • High protection rating of IP67 for harsh environments
  • Wide operational temp range: -25 to 70°C
In Stock Low Stock Out Of Stock Please See Attributes
1

Specifications

General

Product Type
Magnetic Safety Sensor
Brand
Schmersal
Series
BNS-B20

Electrical

No. of N/C Contacts
2
No. of N/O Contacts
1
Plug Type
Connector M12
Rated Current (In)
0.01A
Rated Voltage (Ur)
24V DC

Mechanical

Actuator Type
BNS-B20-B01
Housing Material
Glass-fibre, reinforced thermoplastic

Dimensions & Physical Data

Depth
43.3mm
Height
140mm
Weight
0.105kg
Width
119.5mm

Environmental

Operating Temperature
-25°C to 70°C
IP Rating
IP67
