Schmersal 101176209 Safety Relay Module 24VDC NO

Product Code: 101176209

  • 24 VDC monitoring module with NO contact config
  • Durable roller plunger actuator, 1M cycles lifespan
  • Reinforced glass fibre plastic housing, IP20 rated
  • Complies with EN IEC and ISO standards
  • Handles up to 1000 A current
In Stock Low Stock Out Of Stock Please See Attributes
1

Specifications

General

Product Type
Safety Relay Module
Brand
Schmersal
Series
SRB400CS

Electrical

Switching Current
8:00 AM
Switching Voltage
250 V AC
Supply Voltage
24 V DC

Mechanical

Housing Material
Glass-fibre reinforced thermoplastic, ventilated

Dimensions & Physical Data

Depth
121 mm
Height
100 mm
Weight
235 g
Width
22.5 mm

Environmental

Operating Temperature
-25 to 45 °C
IP Rating
IP40, IP54, IP20

Safety, Standards & Compliance

Safe Relay Outputs, Stop 0
4
Safe Relay Outputs, Stop 1
0
Safety Category
4
Safety Integrity Level
SIL 3
Monitoring Circuit
Yes
Performance Level
PL e

Documents

IPD Product Catalogue V17
