Schmersal 101174589 Solenid Interlock Switch 24VAC/VDC 3NC+1NO

Product Code: 101174589

  • Aluminium housing with IP67 protection
  • 3NC+1NO contact configuration
  • Suitable for 24 VAC/VDC operations
  • Durable with 1 million mechanical cycles
  • Meets cULus and UKCA standards
In Stock Low Stock Out Of Stock Please See Attributes
1

Specifications

General

Product Type
Solenoid Interlock Switch
Brand
Schmersal
Series
AZM 415

Electrical

No. of N/C Contacts
3
No. of N/O Contacts
1
Rated Current (In)
0.25
Rated Voltage (Ur)
24 V AC/DC

Mechanical

Cable Entry
2 x M20 x 1.5
Guard Locking Force
3,500 N
Housing Material
Aluminium

Dimensions & Physical Data

Depth
46.5 mm
Height
100 mm
Weight
952 g
Width
162 mm

Environmental

Operating Temperature
-25_+50
IP Rating
IP54
