Schmersal 101173397 Inductive Proximity Switch NC

Product Code: 101173397

  • Proximity Switch, Series IFL
  • Rated Voltage: 4.5 VDC, Current: 0.5 A
  • Durable Aluminium Housing, IP67 Protection
  • Threaded Mounting with M20 x 1.5 Screw Connection
  • Long Mechanical Life: 20 Million Operations
In Stock Low Stock Out Of Stock Please See Attributes
1

Specifications

General

Product Type
Inductive Proximity Switch
Brand
Schmersal
Series
IFL 385

Electrical

Switching Current
0.5A
Switching Voltage
15V to 250V AC
Type of Actuation
Inductive
Electrical Connection
Screw terminals M20 x 1.5
Switching Distance
50mm

Mechanical

Material
Plastic

Dimensions & Physical Data

Depth
40mm
Height
135mm
Width
80mm
Cable Length
2m

Environmental

Operating Temperature
-25°C to 70°C
IP Rating
IP67

Documents

IPD Product Catalogue V17
