Schmersal 101171394 Medium-Duty Position Switch 1NO Grey Cast Iron Galvanized Silver Contact

Product Code: 101171394

  • Durable grey cast iron housing
  • IP65 protection against dust and water
  • Rated for 400 VAC and 4 A
  • Silver contact, slow action switch
  • Long mechanical life: 10 million ops
In Stock Low Stock Out Of Stock Please See Attributes
1

Specifications

General

Product Type
Position Switch
Brand
Schmersal
Series
452 roller lever D

Electrical

No. of N/O Contacts
2
Rated Insulation Voltage (Ui)
400V
Rated Current (In)
4A (AC-15)
Rated Voltage (Ur)
400V AC (AC-15)
Terminal Type
Screw
Thermal Test Current
16A

Mechanical

Actuator Type
Roller lever
Contact Material
Silver
Housing Material
Grey cast iron, galvanised

Dimensions & Physical Data

Depth
64mm
Height
265mm
Weight
1,975g
Width
118mm

Environmental

IP Rating
IP65
Ambient Temperature
-40°C to 90°C

Documents

IPD Product Catalogue V17
