Schmersal 101170840 Output Expander NO-NC

Product Code: 101170840

  • Rated current: 1000 A
  • NO-NC contact configuration
  • Aluminium housing, IP40 protection
  • Mechanical life: 1 million cycles
  • Slow action with positive break NC contact
In Stock Low Stock Out Of Stock Please See Attributes
1

Specifications

General

Product Type
Output Expander
Brand
Schmersal
Series
SRB402EM

Electrical

Switching Current
6:00 AM
Switching Voltage
250 V AC
Supply Voltage
24 V AC, 24 V DC

Mechanical

Housing Material
Glass-fibre reinforced thermoplastic, ventilated

Dimensions & Physical Data

Depth
121 mm
Height
120 mm
Weight
250 g
Width
22.5 mm

Environmental

Operating Temperature
-25 to 45 °C
IP Rating
IP40, IP54, IP20

Safety, Standards & Compliance

Auxiliary Relay Outputs
2
Safe Relay Outputs, Stop 0
4
Safe Relay Outputs, Stop 1
0
Safety Category
4
Safety Integrity Level
SIL 3
Monitoring Circuit
Yes
Performance Level
PL e
