Schmersal 101170496 Medium-Duty Position Switch K360 Offset Roller Lever NC Aluminium Silver Contact

Product Code: 101170496

  • Robust aluminium housing, IP65 protection
  • Slow action, positive break NC contact
  • Offset roller lever actuator for precise control
  • Rated current of 1000 A with silver contacts
  • Long mechanical life: 1 million operations
In Stock Low Stock Out Of Stock Please See Attributes
1

Specifications

General

Product Type
Position Switch
Brand
Schmersal
Series
441 roller lever L

Electrical

No. of N/C Contacts
1
No. of N/O Contacts
1
Rated Insulation Voltage (Ui)
250V
Rated Current (In)
4A (AC-15)
Rated Voltage (Ur)
250V AC (AC-15)
Terminal Type
Screw
Thermal Test Current
16A

Mechanical

Actuator Type
Roller lever
Contact Material
Silver
Housing Material
Grey cast iron, galvanised

Dimensions & Physical Data

Depth
63mm
Height
192mm
Weight
1,655g
Width
106mm

Environmental

IP Rating
IP65
Ambient Temperature
-40°C to 90°C

Documents

IPD Product Catalogue V17
