Schmersal 101170463 Medium-Duty Position Switch R300 Roller Plunger 1NO-1NC Aluminium Silver Contact

Product Code: 101170463

  • Durable aluminium housing, IP65 rated
  • 1NO+1NC contact config with silver contacts
  • Slow action, positive break NC contact
  • R300 roller plunger actuator, 0.3 m/s speed
  • Meets BG-GS-ET-14 & ENIEC 60947-5-3 standards
In Stock Low Stock Out Of Stock Please See Attributes
1

Specifications

General

Product Type
Position Switch
Brand
Schmersal
Series
441 roller lever D

Electrical

No. of N/C Contacts
1
No. of N/O Contacts
1
Rated Insulation Voltage (Ui)
400V
Rated Current (In)
4A (AC-15)
Rated Voltage (Ur)
400V AC (AC-15)
Terminal Type
Screw
Thermal Test Current
16A

Mechanical

Actuator Type
Roller lever
Contact Material
Silver
Housing Material
Grey cast iron, galvanised

Dimensions & Physical Data

Depth
63mm
Height
237mm
Weight
1,675g
Width
106mm

Environmental

IP Rating
IP65
Ambient Temperature
-40°C to 90°C

Documents

IPD Product Catalogue V17
