Schmersal 101168078 Micro Switch Leaf Spring Lever Shape 2H 1CO Die Cast Light Alloy

Product Code: 101168078

  • Rated Current: 6 A
  • Durable die-cast light alloy housing
  • IP65 protection against dust and water
  • Snap action switching with leaf spring lever
  • Long mechanical life of 30 million operations
In Stock Low Stock Out Of Stock Please See Attributes
1

Specifications

General

Product Type
Micro Switch
Brand
Schmersal

Electrical

No. of N/C Contacts
1
No. of N/O Contacts
1
Switching Element
Change-over contact with double break
Switching Principle
Snap action with self-cleaning contact
Terminal Type
Screw terminals
Thermal Test Current
6A

Mechanical

Actuator Type
Leaf spring lever shape 2H
Contact Material
Silver
Housing Material
Light alloy die-casting

Environmental

IP Rating
IP65
Ambient Temperature
-30°C to 90°C

Documents

IPD Product Catalogue V17
