Schmersal 101167191 Solenid Interlock Switch 110VAC NO+NC

Product Code: 101167191

  • Durable aluminium housing, IP67 protection
  • Supports 110 VAC, 4 A operation
  • Long-lasting with 1 million cycles
  • Slow action with NO+NC contacts
  • Certified: cULus, CCC, UKCA
In Stock Low Stock Out Of Stock Please See Attributes
1

Specifications

General

Product Type
Solenoid Interlock Switch
Brand
Schmersal
Series
AZM 415

Electrical

No. of N/C Contacts
2
No. of N/O Contacts
2
Rated Current (In)
0.25
Rated Voltage (Ur)
110 V AC
Terminal Type
Screw terminals

Mechanical

Cable Entry
2 x M20 x 1.5
Guard Locking Force
3,500 N
Housing Material
Aluminium

Dimensions & Physical Data

Depth
46.5 mm
Height
100 mm
Weight
920 g
Width
130 mm

Environmental

Operating Temperature
-25_+50
IP Rating
IP67

Documents

IPD Product Catalogue V17
