Schmersal 101166285 Solenid Interlock Switch NO+NC

Product Code: 101166285

  • Roller Lever actuator for precise control
  • Durable die-cast light alloy housing
  • High protection with IP67 rating
  • Long life: 1 million mechanical cycles
  • Certified by IFA, cULus, CCC, UKCA
In Stock Low Stock Out Of Stock Please See Attributes
1

Specifications

General

Product Type
Solenoid Interlock Switch
Brand
Schmersal
Series
AZM 161

Electrical

No. of N/C Contacts
4
No. of N/O Contacts
2
Switching Current
4A (AC-15), 2.5A (DC-13)
Switching Voltage
230 VAC (AC-15), 24V DC (DC-13)
Rated Voltage (Ur)
24V AC/ DC (control)
Terminal Type
Connector M12, 8-pole
Operating Mode
Power-to-lock

Mechanical

Actuator Type
Separate actuator
Cable Entry
4 × M16 × 1.5
Guard Locking Force
2000N
Housing Material
Glass-fibre reinforced thermoplastic

Dimensions & Physical Data

Depth
30mm
Height
90mm
Weight
0.46kg (approx.)
Width
130mm

Environmental

IP Rating
IP67
Ambient Temperature
-25°C to 60°C
