Schmersal 101165310 Magnetic Reed Switch 3A M20 x 1.5 Screw Terminal

Product Code: 101165310

  • Magnetic Reed Switch, Series BN20
  • Rated for 250 VAC & 3 A
  • Durable glass fibre reinforced housing
  • IP67 protection for harsh environments
  • NO+NC contact configuration
In Stock Low Stock Out Of Stock Please See Attributes
1

Specifications

General

Product Type
Magnetic Reed Switch
Brand
Schmersal
Series
BN 20

Electrical

Configuration Type
NC contact, NO contact
No. of N/C Contacts
1
No. of N/O Contacts
1
Switching Current
3:00 AM
Switching Voltage
250 V AC
Electrical Connection
2 x M16 x 1.5

Mechanical

Material
Aluminium

Dimensions & Physical Data

Depth
47 mm
Height
52 mm
Weight
300 g
Width
104 mm

Environmental

Operating Temperature
-25 to 90 degC
IP Rating
IP67

Documents

IPD Product Catalogue V17
