Schmersal 101164827 Position Switch H200 Roller Lever NC Silver Contact

Product Code: 101164827

  • Durable glass fibre reinforced thermoplastic housing
  • IP65 rating for robust protection
  • Snap action switching with H200 roller lever
  • M12 connector, 4 pole terminal type
  • Complies with ENIEC 60947 standards
In Stock Low Stock Out Of Stock Please See Attributes
1

Specifications

General

Product Type
Position Switch
Brand
Schmersal
Series
441 roller lever D

Electrical

No. of N/C Contacts
1
No. of N/O Contacts
1
Rated Insulation Voltage (Ui)
250V
Rated Current (In)
4A (AC-15)
Rated Voltage (Ur)
250V AC (AC-15)
Terminal Type
Screw
Thermal Test Current
16A

Mechanical

Actuator Type
Roller lever
Contact Material
Silver
Housing Material
Grey cast iron, galvanised

Dimensions & Physical Data

Depth
63mm
Height
237mm
Weight
1,695g
Width
106mm

Environmental

IP Rating
IP65
Ambient Temperature
-30°C to 90°C
