Schmersal 101164306 Position Switch Plunger 1NO Grey Cast Iron Galvanized Silver Contact

Product Code: 101164306

  • Rated current of 4 A for reliable performance
  • Durable grey cast iron housing, galvanized finish
  • IP65 protection for harsh environments
  • Complies with ENIEC 60947-5-1 standards
  • Plunger actuator type with silver contacts
In Stock Low Stock Out Of Stock Please See Attributes
1

Specifications

General

Product Type
Position Switch
Brand
Schmersal
Series
422 plunger S

Electrical

No. of N/O Contacts
1
Rated Current (In)
4A (AC-15)
Rated Voltage (Ur)
400V AC (AC-15)
Terminal Type
Screw
Thermal Test Current
16A

Mechanical

Actuator Type
Plunger
Contact Material
Silver
Housing Material
Grey cast iron, galvanised

Dimensions & Physical Data

Depth
63mm
Height
97mm
Weight
1,053g
Width
106mm

Environmental

IP Rating
IP65
Ambient Temperature
-40°C to 90°C
