Schmersal 101163279 Position Switch Plunger NC Grey Cast Iron Galvanized Silver Contact

Product Code: 101163279

  • Rated Voltage: 400 VAC, Current: 4 A
  • IP65 protection for harsh environments
  • Durable grey cast iron housing
  • Slow action NC contact configuration
  • High mechanical life of 10 million ops
In Stock Low Stock Out Of Stock Please See Attributes
1

Specifications

General

Product Type
Position Switch
Brand
Schmersal
Series
422 plunger S

Electrical

No. of N/C Contacts
1
Rated Insulation Voltage (Ui)
400V
Rated Current (In)
4A (AC-15)
Rated Voltage (Ur)
400V AC (AC-15)
Terminal Type
Screw
Thermal Test Current
16A

Mechanical

Actuator Type
Plunger
Contact Material
Silver
Housing Material
Grey cast iron, galvanised

Dimensions & Physical Data

Depth
63mm
Height
97mm
Weight
1,200g
Width
106mm

Environmental

IP Rating
IP65
Ambient Temperature
-40°C to 90°C

Documents

IPD Product Catalogue V17
