Schmersal 101163278 Position Switch Plunger 1NO-1NC Grey Cast Iron Galvanized Silver Contact

Product Code: 101163278

  • Robust grey cast iron housing
  • High protection rating of IP66
  • Mechanical plunger actuator
  • 1NO+1NC silver contacts
  • Rated for 16A current
In Stock Low Stock Out Of Stock Please See Attributes
1

Specifications

General

Product Type
Position Switch
Brand
Schmersal
Series
422 plunger S

Electrical

No. of N/C Contacts
1
Rated Current (In)
4A (AC-15)
Rated Voltage (Ur)
400V AC (AC-15)
Terminal Type
Screw
Thermal Test Current
16A

Mechanical

Actuator Type
Plunger
Contact Material
Silver
Housing Material
Grey cast iron, galvanised

Dimensions & Physical Data

Depth
63mm
Height
97mm
Weight
1,250g
Width
106mm

Environmental

IP Rating
IP65
Ambient Temperature
-40°C to 90°C
