Schmersal 101161646 Position Switch Roller Lever Aluminium

Product Code: 101161646

  • Durable aluminium housing
  • IP65 protection rating
  • Roller lever actuator
  • Mechanical switching mechanism
  • 10 million operation lifespan
In Stock Low Stock Out Of Stock Please See Attributes
1

Specifications

General

Product Type
Position Switch
Brand
Schmersal
Series
441 roller lever L

Electrical

No. of N/C Contacts
1
No. of N/O Contacts
1
Rated Insulation Voltage (Ui)
400V
Rated Current (In)
4A (AC-15)
Rated Voltage (Ur)
400V AC (AC-15)
Terminal Type
Screw
Thermal Test Current
16A

Mechanical

Actuator Type
Roller lever
Contact Material
Silver
Housing Material
Aluminium

Dimensions & Physical Data

Depth
63mm
Height
192mm
Weight
0.975kg
Width
106mm

Environmental

IP Rating
IP65
Ambient Temperature
-30°C to 90°C

Documents

IPD Product Catalogue V17
