Schmersal 101161515 Pull-Wire Switch

Product Code: 101161515

In Stock Low Stock Out Of Stock Please See Attributes
1

Specifications

General

Product Type
Position Switch
Brand
Schmersal
Series
441

Electrical

Rated Impulse Withstand Voltage (Uimp)
4 kV
Rated Insulation Voltage (Ui)
400 V
Switching Principle
Slow action; overlapping contacts
Utilization Category
Rated 380 VAC / 4 A
Contact Configuration
1 NC + 1 NO
Mechanical Life
30,000 operations
Thermal Test Current
10:00 AM

Mechanical

Cable Cross Section
max. 4 mm²
Cable Entry
Screw terminals; 2 x M20 x 1.5 mm² cable entries
Contact Material
Silver
Housing Material
Light-alloy die-cast housing, painted; steel cover

Dimensions & Physical Data

Depth
63
Height
99
Weight
1.34 kg
Width
106

Environmental

IP Rating
IP65
Ambient Temperature
-30 ... +120 °C

Safety, Standards & Compliance

Standards and Approvals
CCC; EN IEC 60947-5-1
