Schmersal 101160652 Safety Switch with Separate Actuator NC 5m Cable

Product Code: 101160652

  • Rated for 1000 A current capacity
  • Durable with 1,000,000 cycles lifespan
  • IP67 protection against dust and water
  • Operates in -30 to 80°C temperature range
  • Reinforced thermoplastic housing for durability
In Stock Low Stock Out Of Stock Please See Attributes
1

Specifications

General

Product Type
Safety Switch With Separate Actuator
Brand
Schmersal
Series
AZ 17

Electrical

No. of N/C Contacts
2
Rated Current (In)
0.166667
Rated Voltage (Ur)
230 V AC / 24 V DC
Terminal Type
Pre-wired cable

Mechanical

Cable Entry
Pre-wired cable
Housing Material
Plastic, glass-fibre reinforced thermoplastic, self-extinguishing

Dimensions & Physical Data

Depth
30 mm
Height
65 mm
Weight
600 g
Width
30 mm

Environmental

Operating Temperature
-30 to 80 °C
IP Rating
IP67

Documents

IPD Product Catalogue V17
