Products

Schmersal 101160083 Position Switch 250VAC 1NO+1NC

Product Code: 101160083

  • Rated for 250 VAC and 4 A
  • Durable aluminium housing, IP65 protection
  • Operates from -40 to 200°C
  • Snap action with roller plunger
  • Long mechanical life: 5 million cycles
In Stock Low Stock Out Of Stock Please See Attributes
1

Specifications

General

Product Type
Position Switch
Brand
Schmersal

Electrical

No. of N/C Contacts
1
No. of N/O Contacts
1
Rated Insulation Voltage (Ui)
400V
Terminal Type
Screw terminals
Thermal Test Current
16A

Mechanical

Actuator Type
Roller plunger
Housing Material
Aluminium

Dimensions & Physical Data

Depth
63mm
Height
145mm
Weight
0.62kg
Width
106mm

Environmental

IP Rating
IP65
Ambient Temperature
-40°C to 200°C

Documents

IPD Product Catalogue V17
