Schmersal 101157376 Safety switch with separate actuator 1NO+1NC

Product Code: 101157376

  • Rated for 1000 A with slow action mechanism
  • Durable aluminium housing, IP30 protection
  • Operates in -30 to 70°C temperature range
  • Long mechanical life of 1 million cycles
  • Complies with EN IEC safety standards
In Stock Low Stock Out Of Stock Please See Attributes
1

Specifications

General

Product Type
Safety Switch With Separate Actuator
Brand
Schmersal
Series
AZ 15

Electrical

No. of N/C Contacts
1
Rated Current (In)
0.166667
Rated Voltage (Ur)
230 V AC / 24 V DC
Terminal Type
Screw terminals

Mechanical

Housing Material
Plastic, glass-fibre reinforced thermoplastic, self-extinguishing

Dimensions & Physical Data

Depth
30 mm
Height
75 mm
Weight
95 g
Width
52 mm

Environmental

Operating Temperature
-40 to 80 °C
IP Rating
IP67
