Schmersal 101157375 Safety switch with separate actuator NC

Product Code: 101157375

  • Rated current of 1000 A
  • Durable aluminium housing, IP54 protection
  • Operates in -30 to 70°C temperatures
  • Long mechanical life: 1 billion cycles
  • Complies with EN IEC 61496 standards
In Stock Low Stock Out Of Stock Please See Attributes
1

Specifications

General

Product Type
Safety Switch With Separate Actuator
Brand
Schmersal
Series
AZ 15 (AZ 15 ZVK-M20)

Electrical

No. of N/C Contacts
1
Rated Current (In)
4A (AC-15, 230V AC) / 4A (DC-13, 24V DC)
Rated Voltage (Ur)
230V AC (AC-15) / 24V DC (DC-13)
Terminal Type
Screw terminals

Mechanical

Cable Entry
3 × M20 × 1.5
Housing Material
Glass-fibre reinforced thermoplastic

Dimensions & Physical Data

Depth
30mm
Height
75mm
Weight
0.1kg
Width
52mm

Environmental

IP Rating
IP67
Ambient Temperature
-30°C to 80°C
