Schmersal 101151298 Safety Switch with Separate Actuator 1NO+1NC

Product Code: 101151298

  • Rated current of 1000 A for high capacity
  • Durable aluminium housing, IP67 rated
  • Roller lever actuator with slow action
  • Long mechanical life: 1 million cycles
  • Complies with EN IEC 61496 standards
In Stock Low Stock Out Of Stock Please See Attributes
1

Specifications

General

Product Type
Safety Switch With Separate Actuator
Brand
Schmersal
Series
AZ 15

Electrical

No. of N/C Contacts
1
Rated Current (In)
0.166667
Rated Voltage (Ur)
230 V AC / 24 V DC
Terminal Type
Screw terminals

Mechanical

Housing Material
Plastic, glass-fibre reinforced thermoplastic, self-extinguishing

Dimensions & Physical Data

Depth
30 mm
Height
75 mm
Weight
95 g
Width
52 mm

Environmental

Operating Temperature
-30 to 80 °C
IP Rating
IP67
