Schmersal 101150635 Safety Switch with Separate Actuator 230VAC 1NO+2NC

Product Code: 101150635

  • Rated voltage: 230 VAC, current: 4 A
  • IP67 protection; durable in harsh conditions
  • Straight, rigid actuator; reliable operation
  • Meets EN ISO safety standards
  • Long life: 1 million mechanical cycles
In Stock Low Stock Out Of Stock Please See Attributes
1

Specifications

General

Product Type
Safety Switch With Separate Actuator
Brand
Schmersal
Series
AZ 16

Electrical

No. of N/C Contacts
2
No. of N/O Contacts
1
Rated Current (In)
0.166667
Rated Voltage (Ur)
230 V AC / 24 V DC
Terminal Type
Screw terminals

Mechanical

Cable Entry
3 x M20 x 1.5
Housing Material
Plastic, glass-fibre reinforced thermoplastic, self-extinguishing

Dimensions & Physical Data

Depth
30 mm
Height
90 mm
Weight
195 g
Width
52 mm

Environmental

Operating Temperature
-30 to 80 °C
IP Rating
IP67
