Schmersal 101147467 Safety Switch with Separate Actuator 230VAC 1NO+1NC

Product Code: 101147467

  • Durable plastic, glass fibre reinforced housing
  • IP67 protection for harsh environments
  • Operates in -30 to 80°C range
  • 1NO+1NC contact configuration
  • Meets cULus and EN standards
In Stock Low Stock Out Of Stock Please See Attributes
1

Specifications

General

Product Type
Safety Switch With Separate Actuator
Brand
Schmersal
Series
AZ 17

Electrical

No. of N/C Contacts
1
No. of N/O Contacts
1
Terminal Type
Pre-wired cable

Mechanical

Cable Entry
Pre-wired cable
Housing Material
Plastic, glass-fibre reinforced thermoplastic, self-extinguishing

Dimensions & Physical Data

Depth
30mm
Height
65mm
Weight
0.439kg
Width
30mm

Environmental

Operating Temperature
-30°C to 80°C
IP Rating
IP67
