Schmersal 101140795 Solenid Interlock Switch 24VAC/VDC 2NC

Product Code: 101140795

  • Operates at 24 VAC/VDC, handling up to 1000 A
  • Durable with 10 million mechanical cycles
  • IP67 protection for harsh environments
  • Compact size: 44mm L x 25mm H
  • Screw mount with glass fibre reinforced thermoplastic housing
In Stock Low Stock Out Of Stock Please See Attributes
1

Specifications

General

Product Type
Solenoid Interlock Switch
Brand
Schmersal
Series
AZM 170

Electrical

No. of N/C Contacts
2
Rated Voltage (Ur)
24V AC/DC

Mechanical

Cable Entry
1 x M20 x 1.5
Guard Locking Force
1,000N
Housing Material
Plastic, glass-fibre reinforced thermoplastic, self-extinguishing

Dimensions & Physical Data

Depth
30mm
Height
84mm
Weight
0.288kg
Width
90mm

Environmental

Operating Temperature
-25°C to 70°C
IP Rating
IP67

Documents

IPD Product Catalogue V17
