Schmersal 101140772 Safety Switch with Separate Actuator 1NO+1NC

Product Code: 101140772

  • Safety switch with 1NO+1NC contacts
  • Magnet actuator, slow action design
  • Robust IP67 protection for harsh environments
  • Operates in -30 to 80°C temperature range
  • Durable with 30 million mechanical cycles
In Stock Low Stock Out Of Stock Please See Attributes
1

Specifications

General

Product Type
Safety Switch With Separate Actuator
Brand
Schmersal
Series
AZ 17

Electrical

No. of N/C Contacts
1
No. of N/O Contacts
1
Terminal Type
Connector plug M12, 4-pole, (A-coding)

Mechanical

Housing Material
Plastic, glass-fibre reinforced thermoplastic, self-extinguishing

Dimensions & Physical Data

Depth
30mm
Height
78.5mm
Weight
0.085kg
Width
30mm

Environmental

Operating Temperature
-30°C to 80°C
IP Rating
IP67

Documents

IPD Product Catalogue V17
