Schmersal 101138333 Safety Switch with Separate Actuator 230VAC 1NO+1NC 6m Cable

Product Code: 101138333

  • IP67 protection for harsh environments
  • Durable 1M cycle mechanical life
  • Operates in -30 to 80°C range
  • Slow action with positive break NC contact
  • Compact size: 30mm x 30mm x 65mm
In Stock Low Stock Out Of Stock Please See Attributes
1

Specifications

General

Product Type
Safety Switch With Separate Actuator
Brand
Schmersal
Series
AZ 17

Electrical

No. of N/C Contacts
1
No. of N/O Contacts
1
Terminal Type
Pre-wired cable

Mechanical

Cable Entry
Pre-wired cable
Housing Material
Plastic, glass-fibre reinforced thermoplastic, self-extinguishing

Dimensions & Physical Data

Depth
30mm
Height
65mm
Weight
0.49kg
Width
30mm

Environmental

Operating Temperature
-30°C to 80°C
IP Rating
IP67
