Schmersal 101136474 Safety Switch with Separate Actuator 230VAC 1NO+1NC

Product Code: 101136474

  • Rated for 230 VAC, 4 A
  • Durable with 1 million cycles life
  • IP67 rated for dust and water protection
  • Compact size: 30mm L x 30mm W x 65mm H
  • Slow action with positive break NC contact
In Stock Low Stock Out Of Stock Please See Attributes
1

Specifications

General

Product Type
Safety Switch With Separate Actuator
Brand
Schmersal
Series
AZ 17

Electrical

No. of N/C Contacts
1
No. of N/O Contacts
1
Terminal Type
Pre-wired cable

Mechanical

Cable Entry
Pre-wired cable
Housing Material
Plastic, glass-fibre reinforced thermoplastic, self-extinguishing

Dimensions & Physical Data

Depth
30mm
Height
65mm
Weight
0.425kg
Width
30mm

Environmental

Operating Temperature
-30°C to 80°C
IP Rating
IP67

Documents

IPD Product Catalogue V17
