Schmersal 101127983 Rotating Spindle Limit Switch Plunger Grey Cast Iron Galvanized

Product Code: 101127983

  • Operates at 230 VAC, 2 A for reliable performance
  • Durable grey cast iron housing, galvanized finish
  • IP65 rated for dust and water protection
  • Complies with ENIEC 60947-5-1 standards
  • Long mechanical life of 3 million operations
In Stock Low Stock Out Of Stock Please See Attributes
1

Specifications

General

Product Type
Position Switch
Brand
Schmersal
Series
MSP 452

Electrical

No. of N/C Contacts
2
No. of N/O Contacts
2
Rated Insulation Voltage (Ui)
250V
Rated Current (In)
2.5A (AC-15)
Rated Voltage (Ur)
230V AC (AC-15)
Terminal Type
Screw
Thermal Test Current
6A

Mechanical

Housing Material
Grey cast iron, galvanised

Dimensions & Physical Data

Depth
64mm
Height
174mm
Weight
1,700g
Width
118mm

Environmental

IP Rating
IP65
Ambient Temperature
-30°C to 90°C

Documents

IPD Product Catalogue V17
