Schmersal 101082364 Magnetic Reed Switch 1m L Cable 0.5A BP 10 Cable Terminal

Product Code: 101082364

  • Rated for 250 VAC, 0.5 A
  • Durable IP67 glass fibre thermoplastic housing
  • Operates from -25 to 75°C
  • Magnetic drive with NC contact configuration
  • Long mechanical life: 1 billion ops
In Stock Low Stock Out Of Stock Please See Attributes
1

Specifications

General

Product Type
Magnetic Reed Switch
Brand
Schmersal
Series
BN 80

Electrical

Configuration Type
Opener (NC)
No. of N/C Contacts
1
No. of N/O Contacts
0
Switching Current
0.5A
Switching Voltage
250V AC, 250V DC
Electrical Connection
Pre-wired cable

Mechanical

Material
Glass-fibre, reinforced thermoplastic

Dimensions & Physical Data

Depth
9mm
Height
13mm
Weight
0.023kg
Width
44mm
Cable Length
1m

Environmental

Operating Temperature
-25°C to 75°C
IP Rating
IP67

Documents

IPD Product Catalogue V17
