Schmersal 101061111 Position Switch Roller Lever 1NO-1NC Grey Cast Iron Galvanized Silver Contact

Product Code: 101061111

  • 230 VAC, 10 A rated for reliable performance
  • Durable grey cast iron housing, IP65 protection
  • Complies with ENIEC 60947-5-1 standards
  • Roller lever actuator with slow action switch
  • Silver contacts ensure efficient conductivity
In Stock Low Stock Out Of Stock Please See Attributes
1

Specifications

General

Product Type
Position Switch
Brand
Schmersal
Series
471 roller lever A

Electrical

No. of N/C Contacts
2
No. of N/O Contacts
2
Rated Insulation Voltage (Ui)
500V
Rated Current (In)
10A (AC-15)
Rated Voltage (Ur)
230V AC (AC-15)
Terminal Type
Screw
Thermal Test Current
25A

Mechanical

Actuator Type
Roller lever
Contact Material
Silver
Housing Material
Grey cast iron, galvanised

Dimensions & Physical Data

Depth
190mm
Height
143mm
Weight
4,920g
Width
194mm

Environmental

IP Rating
IP65
Ambient Temperature
-30°C to 90°C
