Schmersal 101058354 Position Switch Plunger Cast Iron Galvanized

Product Code: 101058354

  • Durable cast iron, galvanized housing
  • IP65 protection against dust and water
  • Complies with ENIEC 60947-5-1 standards
  • Plunger actuator for precise control
  • Long mechanical life: 10 million operations
In Stock Low Stock Out Of Stock Please See Attributes
1

Specifications

General

Product Type
Position Switch
Brand
Schmersal
Series
441 plunger S

Electrical

No. of N/C Contacts
1
No. of N/O Contacts
1
Rated Insulation Voltage (Ui)
400V
Rated Current (In)
4A (AC-15)
Rated Voltage (Ur)
400V AC (AC-15)
Terminal Type
Screw
Thermal Test Current
16A

Mechanical

Actuator Type
Plunger
Contact Material
Silver
Housing Material
Grey cast iron, galvanised

Dimensions & Physical Data

Depth
63mm
Height
125mm
Weight
1,320g
Width
106mm

Documents

IPD Product Catalogue V17
