Schmersal 101057965 Heavy-Duty Position Switch Plunger 1NO-1NC 45mm W Die Cast Light Alloy Painted

Product Code: 101057965

  • Flange mount, IP67 rated limit switch
  • Die cast light alloy housing, painted finish
  • Operates in -25 to 70°C range
  • Gold plated silver contacts for reliability
  • M12 connector terminal type
In Stock Low Stock Out Of Stock Please See Attributes
1

Specifications

General

Product Type
Position Switch
Brand
Schmersal
Series
250 roller lever D

Electrical

No. of N/C Contacts
1
No. of N/O Contacts
1
Rated Insulation Voltage (Ui)
250V
Rated Current (In)
2.5A
Rated Voltage (Ur)
400V AC (AC-15)
Terminal Type
Screw
Thermal Test Current
16A

Mechanical

Actuator Type
Roller lever
Housing Material
Grey cast iron, galvanised

Dimensions & Physical Data

Depth
125mm
Height
257mm
Weight
3,858g
Width
146mm

Environmental

IP Rating
IP67
Ambient Temperature
-30°C to 90°C

Documents

IPD Product Catalogue V17
