Schmersal 101056572 Position Switch Offset Roller Lever 1NO 72mm H x 40mm W x 60mm D W Silver Contact

Product Code: 101056572

  • Rated current of 12 A for robust performance
  • Durable glass fibre reinforced thermoplastic housing
  • IP66/IP67 protection against dust and water
  • Operates in temperatures from -25 to 70°C
  • Offset roller lever with slow action switching
In Stock Low Stock Out Of Stock Please See Attributes
1

Specifications

General

Product Type
Position Switch
Brand
Schmersal
Series
422 plunger S

Electrical

No. of N/C Contacts
1
Rated Current (In)
4A (AC-15)
Terminal Type
Screw
Thermal Test Current
16A

Mechanical

Actuator Type
Plunger
Contact Material
Silver
Housing Material
Grey cast iron, galvanised

Dimensions & Physical Data

Depth
63mm
Height
97mm
Weight
1,225g
Width
106mm

Environmental

IP Rating
IP65
Ambient Temperature
-30°C to 90°C

Documents

IPD Product Catalogue V17
